Introducing Aquatica 1DX Mark II Underwater Housing for Canon 1DX Mark II Camera
By Chino Mendoza

Aquatica Canon 1D X MkII Housing Preview

Chino Mendoza
Introducing Aquatica 1DX Mark II Underwater Housing for Canon 1DX Mark II Camera

Canon EOS-1DX Mark II is the new flagship camera of canon with arguably the best features to date.  It also produces awesome images and video quality.  The camera boasts a 20.2 MP full frame sensor with dual DIGIC 6+ image processor, a 61-point AF system and up to 4K 60P or Full HD 120P video with dual pixel CMOS Autofocus for fast video autofocus and tracking.

Aquatica has just released housing for Canon EOS-1DX Mark II.  Knowing Aquatica, they have built an underwater housing to endure even the toughest condition.  In addition, housing features to be ergonomically designed.   Aquatica is also including the vacuum system (sensor, valve and pump) with the housing upon purchase. This ensures that the housing is fully sealed and gives the user and peace of mind.



Purchase:  Aquatica 1DX Mark II Housing

U.S. Retail Price:  $4,849

Availability: Now Available at Bluewater Photo





Purchase the Aquatica 1DX Mark II Housing






PRESS RELEASE



Introducing Aquatica 1DX Mark II Housing

Aquatica is proud to announce its new housing for Canon's second generation of its most advanced action photography pro camera, the Canon EOS-1D X Mark II. With easy to reach controls, our new lens gear system and uncompromised viewing, this new Aquatica housing puts the Canon 1DX MKII into the hands of photographers shooting in the world’s most demanding underwater environments.



Canon EOS-1D X Mark II Key Features

>  20.2MP full-frame CMOS sensor  >  61-point High Density Reticular AF II system w/41 cross-type points
>  ISO 100-51,200, expandable to  409,600 >  216-zone, 360k pixel RGB/IR metering sensor
>  4K video at 60fps >  30-1/8000 sec plus bulb; 1/250 sec X-sync
>  Up to 120p frame rate at 1080p >  CFast 2.0 compatible
>  4K frame grab >  Dual CF Card slots
>  14fps/16 in LiveView mode in RAW or JPG >  Built-in GPS
>  2-inch, 1.62 million dot resolution touch-sensitive LCD monitor >  Magnesium alloy body, dust- and weather-sealed



About the Aquatica A1DX Mark II Housing

Housing Built with Quality:

The Canon EOS -1D X MKII has a maximum of 14fps standard/16fps Live View burst rate and up to 170 RAW images per blast when using a Cfast card, as well as improved AF performance and 4K video capture, this camera is destined to the camera of choice for sports photographers, wildlife photographers, and even for studio photography.

This new housing is no exception to Aquatica's manufacture process as it is milled from a solid block of 6061 T6 aircraft grade aluminum. It is then black anodized and for further protection, a resistant, baked at high temperature, polyester electrostatic powder coat paint is added. This ensures that your investment will last a lifetime. This is why Aquatica is your choice for housings!

All video controls are designed for easy reach and smooth operation throughout the housing. This includes a next-generation lens gearing system with a redesigned housing pinion gear and a larger diameter lens gear selection, allowing for smoother transition while zooming/focusing in a video sequence. The Aquatica quick release tray delivers smooth and precise positioning of the camera in the housing and allows the user to insert and remove the camera using a simple push tab, allowing the camera to be removed from the back while keeping a lens and zoom gear attached.

The video record on/off control lever is perfectly located on the right side of the housing. This lever is easily controlled with the thumb using a slight forward motion. All push buttons are made from high quality type 304 stainless steel and operate smoothly for a natural feel and intuitive operation.



 SURVEYOR MOISTURE AND VACUUM SENSOR, PUMP & VALVE INCLUDED!!!



Our A1 DX MkII ships with our new atmospheric pressure sensitive circuitry and moisture detector as well as the valve and pump. We decided to have this add on as a standard feature on your housing to allow you to monitor the vacuum pressure inside the housing.

The moisture detection circuit is on constant guard duty, ready to inform you, by way of an audible and visual signal, of any infiltration, no matter how small this one would be. This advanced SURVEYOR circuit also integrates temperature compensation, preventing change in ambient temperature from affecting its accuracy. A few strokes of a pump will light up a green LED, giving you the confirmation that the housing sealing integrity is impeccable. The Surveyor adds yet another layer to your peace of mind.

With this technological advantage, Aquatica can safely claim of having the most advanced and effective protection system, for your camera equipment on the market today.





Purchase the Aquatica 1DX Mark II Housing




More About the Housing's Unique Features

The A1 DX MarkII housing has three bulkhead access holes ready to accept external accessories such as our Aquatica Remote trigger, our Water Wizard (an external radio transceiver housing) and third party external monitors and other accessories.

The A1 DX MarkII model 20082-NK comes equipped with two classic Nikonos connectors of the newest type, these strobe connectors are easy field interchangeable in minutes, while the 20082-KM model is supplied with a time proven 5-pin Ikelite connector.



Proven Aquatica Performance

More than 30 years of expertise have helped craft this A1 DX MKII ergonomic design. It’s a design strongly influenced by working closely, and listening to the input of professional image makers from around the world. The result is an unparalleled attention to detail and expertly crafted solutions.

Viewing is through our own exceptional Galileo-type eye piece. This high quality and coated optical finder gives a bright and full view of the finder. The A1 DX MarkII is also fully compatible with our accessory Aqua View 180, and Aqua View 45 finder, for those who are seeking the ultimate in still image viewing, these two enhanced Aqua View finders deliver second-to-none clarity, providing tack sharp corner to corner viewing for composing and critical focusing.

The A1 DX MarkII also retains our trademark molded grips, the industry standard of comfort for the last 25 years. Lightweight and molded of one piece, they never come unglued or corrode. On top of both grips, threaded mounting holes are ready to accept the popular mounting bracket of our Technical Lighting Control-Delta 3 system as well as being compatible with most current strobes and lighting arms on the market. An extra mounting point for a focus/video light or other accessories is included on top of the housing and three additional mounting points are provided under the housing for various brackets, supports or tripods.

Of course, the A1 DX MarkII housing belongs to one of the most established and comprehensive port and accessories system of the industry. The Aquatica port system with its critically precise optical property, has been a stable platform on which thousands of photographers have relied on for more than 20 years to produces state of the arts images.

The ruggedness of Aquatica housings is legendary. The lightweight A1 DX MarkII benefits from the finest material available in the metallurgic industry and is carefully crafted from a selected alloy of aircraft-grade aluminum. This housing still has the same standard 90m/328ft depth rating that can be factory upgraded to 130m/425ft depth rating on request. Its knurled knobs and oversized controls mean easy operation in all kinds of diving conditions.



Housing equipped with our 180 Aqua View Finder #20054



Specification:

Depth Rating & Dimension

  • 100 m/328 ft (upgradeable to 130m/426ft)
  • Dimensions: Height: 8.49 inches / Depth: 5.3 inches
  • Width: No grips: 8.63 inches / With grips: 13.03 inches
  • Weight (with grips attached): 8.5 lbs



Construction of Shell

  • 6061 T6 Marine Grade aluminum
  • Anodized to MIL-A-8625 (type 2, Class 2 specification)
  • Powder coated with certified A.A.M.A. 2603-98 Polyester coating
  • Baked at 177C / 350F (specification ASTM D2794)



Mounting Points for Strobes Arms, Lighting Fixtures and/or Tripod

  • 5 standard ¼”-20 sized threaded holes, two on each hand grips and one centered on top of the housing
  • 3 standard ¼”-20 sized threaded holes located at the base of the housing
  • Standard features last line
  • 5 bulkhead access entry point for various accessories



Control Shafts and Push Pins

  • Type 304 marine grade Stainless steel
  • All shaft double sealed with double O-rings
  • All push pins sealed with Quad Rings



Standard Features

  • Ergonomically optimized for diving conditions
  • Oversized knurled controls knobs
  • Sturdy comfortable grips
  • Extended shutter release
  • Port lock mechanism
  • Lens release mechanism
  • Standard high quality Galileo Optical Eye piece
  • Dual sacrificial anodes (front and rear mounted)
  • 5 accessory bulkhead entry points
  • Surveyor Moisture and vacuum sensor, pump & valve
  • Form fitting Grips (2x)





Purchase the Aquatica 1DX Mark II Housing


ABOUT THE AUTHOR

Chino Mendoza , is an avid diver and underwater photographer and tries to go everytime he can.  He is based in Manila which is a few hours Anilao which is the “critter capital of the Philippines”  He likes to shoot macro and his favorite subjects are nudibranchs and frogfishes.

Get in touch with him via email at lorenzo@bluewaterphotostore.com

View Chino's work:  Facebook     |     Instagram

SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Introducing Fantasea FG7X II Underwater Housing for Canon G7X Mark II Compact Camera
By Chino Mendoza

Fantasea Canon G7X Mark II Housing Overview

Chino Mendoza
Introducing Fantasea FG7X II Underwater Housing for Canon G7X Mark II Compact Camera

Fantasea will be releasing their new arsenal to their underwater compact camera housing line which is the FG7X II.  This is specifically made for the Canon G7X Mark II and was designed for style, durability, full control of functionality and most especially ease of use.

The FG7X II is ideal for outdoor photographers.  May it be for diving, snorkeling, surfing or other watersports.

Fantasea have made sure that the housing can fully access cameras functionality with ease and buttons are clearly labeled.  In addition, the housing is also shock resistant. It housing has a depth rating of 40 meters (130 ft.) but has been successfully tested up to 60m (200 ft.)

Housing comes with free moisture detector, hand strap and lens port cover.

Below is the detailed specification of the housing.



Purchase:  Fantasea FG7X II Underwater Housing

U.S. Retail Price:  $399.95





Fantasea FG7X Features

Functionality

FG7X II is ergonomically designed to fully access camera controls with ease.  They also made the buttons clearly marked to make it visible even underwater.



Protection

FG7X II is made to be durable - shock resistant.  The housing will protect your camera from damaging elements such as water, sand, dust, ice etc.

Housing is also designed to have a double o-ring seal which ensures that your housing is fully sealed.

Fantasea also included a moisture detection and alarm for free.

Housing has a depth rating of 40 meters (200 ft.) but it has been successfully tested at a depth of 60 meters (200 ft.)





Accessories

May it for macro or wide angle, there are numerous wet lenses available to suit your type of shooting.  Housing port ring has a 67mm thread which is popular with the wet lenses out in the market.  *Note: Fantasea Eyedaptor is required when using wet lenses.

Strobes can also be used with this housing and can be fired via fiber optic cable. This illuminates your subject better and make the color pop out.

Other accessories are also available for purchase at Bluewater Photo



Fantasea FG7X Specification

  • Full access to camera controls
  • Clearly marked buttons
  • Shock resistant
  • Double o-ring
  • Moisture detection and alarm
  • 67mm port ring
  • Depth rated to 60 meters / 200 feet
  • Dimensions: 16 x 11 x 12.5 cm (6.3 x 4.33 x 4.92 inches)
  • Weight: 725g



Fantasea FG7XII Underwater Photos

These photos are from testing the Fantasea FG7XII housing over at Catalina Island, California.







ABOUT THE AUTHOR

Chino Mendoza , is an avid diver and underwater photographer and tries to go everytime he can.  He is based in Manila which is a few hours Anilao which is the “critter capital of the Philippines”  He likes to shoot macro and his favorite subjects are nudibranchs and frogfishes.

Get in touch with him via email at lorenzo@bluewaterphotostore.com

View Chino's work:  Facebook     |     Instagram

SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Introducing Aquatica A6300 Underwater Housing for Sony A6300 Mirrorless Camera
By Brent Durand

Aquatica Sony A6300 Housing Overview

Brent Durand
Introducing Aquatica A6300 Underwater Housing for Sony A6300 Mirrorless Camera

The Aquatica Sony a6300 housing is officially announced and will be shipping in late September. One look at the housing photos show that this is a very compact housing designed for this powerful camera.

The Sony a6300 mirrorless interchangeable lens camera is impressive. Priced at under $1000 USD, the camera features some impressive specs: 24MP APS-C sensor, lighting-fast autofocus and 4K video recording in a very small body. Be sure to read our Sony a6300 camera review for all the details.

The Aquatica A6300 housing brings to power of the camera to underwater photo and video shooters in the style that Aquatica is known for; performance that works, no matter what, for whatever shooting style you pursue. A new power saddle extends battery life so that divers aren't limited by the short battery life of the a6300 (no needing to change batteries on the rocking wet bangka in between dives). Interchangeable viewfinders make it easy to travel and swap viewfinders in and out for wide-angle and macro shooting. And adjustable hand grip lets you customize the grip to your finger size, or between your bare finger trips and dry gloves trips. An exaggerated AF-On lever makes back button focus a breeze. And overall, the rounded, streamlined design just looks sexy!



Purchase:  Aquatica A6300 Housing

U.S. Retail Price:  $1,650

Availability: late-September/October at Bluewater Photo





PRESS RELEASE



Introducing Aquatica A6300 Housing

The Aquatica A6300 is a housing designed to be small, compact and easily handled just like the camera that it is designed for. With 24 MP stills and 4K video capabilities coming in at a retail cost of $1000 dollars, the SONY Alpha a6300 is a great camera for the beginner and professional Underwater Photographer alike.



The Sony A6300:

  •  Advanced Auto Focus (4D FOCUS)
    • Fastest Auto Focus for an interchangeable lens digital camera.
    • 425 focus points, the largest number focus points for a Mirrorless camera
  • Electronic Viewfinder
    • 2.4 m-dot XGA (1024 x 768) OLED
    • 120 FPS refresh rate
  • 4K Video
    • First APS-C mirrorless camera capable of 4K video capture
  • Built from a Magnesium alloy and includes dust and moisture resistance



Our Innovations:

This camera is a powerhouse of technology. That being said, it requires a lot of energy to power. Aquatica has carefully looked at all the strengths and challenges of housing a compact camera and used this opportunity to create some options only available with the Aquatica A6300 housing:



Power Saddle:

The Aquatica Digital Power Saddle incorporates an optional rechargeable battery pack that plugs into the camera’s micro usb port and attaches magnetically to the camera’s mounting plate. This option can be purchased with the housing or purchased later as an add-on. Purchasing the Power Saddle will allow both still and video shooters to have the equivalent of two extra batteries in their housing, allowing the extra power they need to fuel their creative visions.





Purchase the Aquatica A6300 Housing




Interchangeable Viewfinders:

Aquatica Digital is proud to announce the support of our Aqua View Finders. The A6300 will come standard with our Aquatica eyepiece and the housing allows the user to switch between our Aqua View 45 and our Aqua View 180 Finders without having to change the LCD window of the housing. Upgrading to these Finders gives the user a 1.2 magnified view of the electronic viewfinder, allowing for improved underwater viewing. These finders are among the best finders available on the market.



Adjustable Hand Grip Support:

Aquatica is world famous for having the most comfortable hand grips on the market and we are excited to announce that these grips have been adapted for the A6300’s smaller size. We have been able to include these grips as part of the A6300 package in the form of highly modular tray to mount either strobes or video lights to the top of the grips. The tray it self can be moved left and right for added comfort. Furthermore, the tray brackets can be independently adjusted to a forward, mid and back position while the grip brackets can be adjusted to an inward, centered and outward position from the housing, thus allowing for you to have industry’s most ergonomic control access available. Additionally; an adjustable Aquatica nylon hand strap is included at no extra cost allowing for the avid freediver, or available light shooter to streamline their profile by removing the handles.



The Controls:

The A6300 can be used with or without grips. The right side of the housing has been designed so that you can comfortably hold and operate the housing with your right hand with the shutter button positioned to naturally rest under your index finger.

We have ergonomically placed the control dial at the rear of the housing so that it gives you quick and easy access to shutter speeds, aperture, white balance and the ISO of the camera. Additionally, at the rear of the housing, we have provided access to many of the camera’s functions. The controls can be easily reached by simply moving your thumb, thus allowing you to never have to remove your hand from the shutter lever. Primarily among these controls is the record button which has been given a large red oversized button for ease of use. For those that prefer a steady hold on the housing, the Aquatica grips and shutter extended trigger are available, allowing for a more traditional hold of the housing underwater.



The Housing:

At the core of the design is the shell, machined on a state of the art 5 axis CNC machine from a solid block of 6061 T6 aluminum alloy. The shell is then anodized and painted with a black polyester powder coating. This type of finish is capable of handling the toughest conditions a professional photographer can throw at it.

We are immensely proud of how often our clients at rental dealerships praise our trademark crinkle powder coat finish being as “tough as nails”. What is often noted is that housings that only have an anodized finish do not stand up to the abuse rental housings are exposed to, therefore making Aquatica housings the ideal choice.

Our control shafts and push buttons are made from the finest grade of stainless steel available rather than plastic or less expensive metals. This ensures the most reliable performance on the market.

The housing shell has two entry points for connecting strobes plus two others for adapting various accessories. The housing is sealed with our signature rotary closure made popular on our Amphibico cinema housings.

There is also a large 16mm diameter access point on the left hand side which is ideal for connecting a video monitor. Located on the left hand side is a standard 1/2” diameter access point for the optional Surveyor vacuum valve to ensure a water tight seal prior to your dive, thus giving the shooter watertight piece of mind.



The Strobe Connectors:

Every underwater shooter’s needs are different, as such we offer a full complement of flash triggering options to suit those needs. Whether you use basic fiber optic connections or the hard wired flash connections with which to fire your strobes independently, we have you covered with our impressive line up of available flash connectors.

  • #34000-OPT our fiber optic version will feature our industry standard L-type fiber optic cable connectors
  • #34000-NK our Nikonos type connector with universal hot shoe
  • #34000-IKE our Ikelite type connector with universal hot shoe





Special Offer:

With the purchase of the A6300 housing, add one TLC #77514 DELTA 3 ARM and get a second one free






Port Selection:

We felt that a camera like the Sony a6300 needs to support the best lenses for the best optical results possible. We have created a full line of extension rings and adapters for both our mirrorless ports as well as our standard port line up.

Our support will cover the unbeatable Zeiss Touit 12mm 2.8 rectilinear wide angle lens as well as the ultra-sharp Zeiss Touit 50mm 2.8 macro lens. This is followed by the stellar Sony 90mm 2.8 macro with manual focus support, and of course the industry’s favorite Tokina 10-17mm fisheye Canon mount with Metabones adapter. Last but not least we support the Sony 10-18 and 16-50 “kit” zoom lenses and by popular demand both the Sony 16mm and 18-55mm lenses.



What's in the Box:

  • Anodized 6061-T6 Aluminium Housing
  • Crinkle Powder Coating
  • Best Grips in the Industry (Left and Right)
  • Two Fiberoptic Ports
  • Extended Trigger adapter
  • Extra main sealing O-Ring
  • Extra Port O-Ring
  • Aquatica Standard Eye Piece





Purchase the Aquatica A6300 Housing




SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Ikelite presents three housings for Nikon D500, new Dry Lock port system and other features for this much-anticipated DSLR
By Chino Mendoza

Ikelite Housings for Nikon D500 Overview

Chino Mendoza
Ikelite presents three housings for Nikon D500, new Dry Lock port system and other features for this much-anticipated DSLR

Ikelite introduces their 3 new housings for Nikon D500 and the new Dry Lock port mount.  Ikelite offers 3 underwater housings for Nikon D500; standard four lock port mount, 50ft water housing with Dry Lock port mount and 200ft Dry Lock port mount.

The new Dry Lock port mount was based on the design of Ikelite's mirrorless port system, which has redefined the concept of their port system.

The 20.7 MP Nikon D500 raises the bar in DX format Nikon cameras. The best feature is the revamped autofocus system, which boasts 153 AF points, 99 of which are cross-type. Improved focus tracking and a joystick for quickly adjusting the focal point location help capture fast action. This is a major jump for Nikon and puts the D500 into the consideration set of those who would have previously chosen Canon's dual-pixel AF technology.

In addition, the Nikon D500 has a large viewfinder with 100% coverage, 4K video resolution, and 10 fps continuous shooting with a buffer far larger than similar camera bodies (using XQD mem cards)... that's some processing power! If you haven't yet, you can read our Nikon D500 Pre-Review.



Purchase:  Ikelite D500 Housing with Four Lock Mount / Ikelite D500 Housing with Dry Lock Mount

U.S. Retail Price:  $1,395 / $1,595

Availability: Pre order for Early September on the Four Lock Mount and Pre-order for October on the Dry Lock Mount



Press Release

The "Best Enthusiast DX Offering"

Nikon has finally given us a successor to the D300s camera with fantastic speed and processing power in a relatively compact and durable body. Some highlights include:

  • Same 153-point Autofocus system and EXPEED 5 processor as the Nikon D5
  • 4K/UHD video recording
  • 20.9MP APS-C CMOS sensor
  • Excellent low light performance with an ISO range of 100-51,200
  • Same rugged weather sealing as the Nikon D810

The D500 is up to almost any photographic challenge—so it's fitting to offer a housing system that can be built to suit almost any need. Three base housing versions are available to suit the Nikon D500 DSLR camera. Skip to the side-by-side comparison...

All three versions start with a fully functional, white ABS-PC housing front which is depth rated to 200' (60m).


Form + Function

The D500 slides into the form fitting housing using a simple tripod-style attachment. Controls are provided for all important camera functions and positioned intuitively to take advantage of the muscle memory you develop when using the camera on the surface. A unique universal gearing system puts zoom or focus at the tip of your finger with a brand new soft-touch, 5-lobed knob.



The AF-ON Trick

Take full advantage of the camera's superb autofocus system and fast continuous frame rate by using AF-ON to lock focus. A convenient lever on the side of the housing feels so natural that we promise you'll never think about half-pressing the shutter again.



Groovy Groove-less O-ring

O-ring channels trap dirt and debris, and cause the o-ring to twist and deform in various ways. Our unique groove-less design is the most user friendly and reliable sealing method currently available. For added assurance, the all-clear back allows you to see the o-ring form a solid, black line once the housing is sealed.



Very Flashy

Optical slaves have come a long way, but electrical sync cords are still the fastest and most precise way to trigger a strobe under water. Each housing comes equipped with a manual flash hot shoe and Ikelite ICS-5 bulkhead. The hot shoe and bulkhead are user changeable for in-field modifications and serviceability.

An optional TTL hot shoe and Nikon TTL Converter provide industry leading accuracy in exposure when combined with a compatible Ikelite DS strobe.

The flash system is almost endlessly expandable with lots of options for remote units triggered by extension cords, optical slaves, Pocket Wizards, and more. It's time to get creative with your lighting and think way beyond the classic two-strobe set-up.



Lens Port Authority

And now... the main event. Introducing the NEW Dry Lock (DL) Port Mount. Building off of our popular port system for compact mirrorless cameras, we have re-designed and refined the concept and it's ready for the big leagues. Key features include:

  • A unique exterior o-ring which prevents water from dripping onto your camera when the port is removed;
  • Solid, sure-stop press fit with no threading, turning, or twisting of the ports or extensions;
  • Built for reliability in remote locations with standard locking thumbscrews and no complex moving parts;
  • Accommodates large diameter lenses with ease;
  • A new compact 8" dome port provides the optical quality of a large dome with the size of a much smaller dome—perfect for close-focus wide angle work;
  • Plus the new featherweight full 8" dome is less than half the weight of its predecessor and several pounds lighter than the glass alternatives with nearly identical optical quality!



Not quite ready to let go of your legacy ports? The Four Lock (FL) version can be sent in at a later date for upgrade to the DL mount. However, our original standard flat, 6" dome, and modular port components are not adaptable to the new system. We promise that once you switch over, you won't miss them anyway...



Our new white ABS-PC blend is specially formulated for added strength and durability. Compared to black, colored, or clear alternatives, the white shell keeps the camera running cooler, longer in hot, sunny climates.



Two Faced... and Two Backed?

The new 50ft (15m) Water Housing version features a slimmed down acrylic back and paired down control set which is over 1/2 pound lighter and streamlined for use at the surface of the water, in surf and pool work. The two backs are interchangeable and can be purchased separately so you can pack lighter when shooting the whale sharks in Isle Mujeres or dolphins in the Red Sea.



Two Faced... and Two Backed?

The new 50ft (15m) Water Housing version features a slimmed down acrylic back and paired down control set which is over 1/2 pound lighter and streamlined for use at the surface of the water, in surf and pool work. The two backs are interchangeable and can be purchased separately so you can pack lighter when shooting the whale sharks in Isle Mujeres or dolphins in the Red Sea.



Side-by-Side Comparison

Three housing versions are available to suit the Nikon D500 DSLR camera. All versions feature:

  • Controls for Shutter-release button, Power switch, Movie-record button, Sub-command dial, Exposure compensation (+/-) button, ISO button, MODE button, WB button, Metering button, BKT button, Lens release button, AF-ON button, Main command dial, Multi selector, Info button, Live view selector, Lv button, i button, Playback button, Trash button, MENU button, Key/? button, Magnify + button, Magnify - button, OK button, Fn2 button
  • Ikelite ICS-5 bulkhead and manual flash hot shoe
  • Aluminum base with Left-Hand Quick Release Handle
  • A completely clear back for an unobstructed view of the camera and o-ring seal
  • Control symbols laser etched into the back for easy to read labeling that will never fade or rub off
  • A quick install camera mount plate which does not need to be removed for battery or memory card access
  • 1 year limited warranty

200ft Underwater Housing
with Four Lock Port Mount
50ft Water Housing
with Dry Lock Port Mount
200ft Water Housing
with Dry Lock Port Mount
Model Number6812.57300571005
PurposeSupport older lens ports for legacy usersLightweight for pool, surf, and use near the surface of the waterFully functional and fully depth rated
Depth Rating200ft/60m200ft/60m Front-50ft/15m Back200ft/60m
Port SystemLegacy Four Lock (FL)Dry Lock (DL)Dry Lock (DL)
Vacuum SystemOptionalIncludedIncluded
Additional Controls
i Button
Trash Button
Key/?Button
Maginfy + Button
Maginfy - Button
Fn2 Button
None
i  Button
Trash Button
Key/?Button
Maginfy + Button
Maginfy - Button
Fn2 Button
Spare 1/2-20 Threaded Ports211
ViewFinder
SuperEye Viewfinder
Optional Straight
45° Magnified Viewfinder
Glass Viewfinder
Optional Straight
45° Magnified Viewfinder
SuperEye Viewfinder
Optional Straight
45° Magnified Viewfinder
US MSRP$1,395$1,395$1,595
AvailabilityPre-order for Early SeptemberPre-order for OctoberPre-order for October
Full DetailsSee 200ft Housing with Four Lock MountSee 50ft Housing with DryLock MountSee 200ft Housing with DryLock Mount










Purchase:  Ikelite D500 Housing with Four Lock Mount / Ikelite D500 Housing with Dry Lock Mount




ABOUT THE AUTHOR

Chino Mendoza , is an avid diver and underwater photographer and tries to go everytime he can.  He is based in Manila which is a few hours Anilao which is the “critter capital of the Philippines”  He likes to shoot macro and his favorite subjects are nudibranchs and frogfishes.

Get in touch with him via email at lorenzo@bluewaterphotostore.com

View Chino's work:  Facebook     |     Instagram

SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




We review specs, innovative touch screen access, ergonomics, and sample content shot with the Fantasea FG9 X underwater housing
By Brent Durand

Fantasea Canon G9 X Housing Review

Brent Durand
We review specs, innovative touch screen access, ergonomics, and sample content shot with the Fantasea FG9 X underwater housing



The Fantasea FG9X housing is the latest in a great line of compact camera housings and will be a staple in the world of compact camera underwater photography. The housing is a great way or beginners to get their G9X into the water, but also allows access to all camera functionality, and when combined with wet lens accessories, strobes and lights, becomes a very powerful underwater imaging system.

The Canon G9 X is the smallest compact camera available with a 1" image sensor. This large high-sensitivity 20.9 megapixel CMOS sensor delivers stunning image quality on par with the best compacts on the market, combined with Canon's very fast DIGIC 6 processor. The lens shoots from f/2.0 - f/4.9 with a 3x optical zoom (equivalent to a 28-84mm lens) for great versatility above and below the surface. A minimum focus distance of 2 inches (in macro mode) enables you to shoot tiny macro critters even before adding a diopter.

Read our overview and comparison of the Best Compact Cameras of Summer 2016.

The Fantasea FG9X housing has been designed to optimize control of the G9 X underwater, with access to all camera buttons, ergonomic and clearly labeled controls, as well as access to essential contact points on the camera's rear LCD touch screen. We'll take a deeper look at the FG9X in this housing review and overview.






Learn more and purchase the Fantasea FG9X Housing




Jump to review section:

Housing Highlights     |     Overview and Controls     |     Advanced Features     |     Demo Video

Recommended Accessories     |     Sample Photos     |     Conclusion



Fantasea FG9X Housing Highlights

  -  Canon G9 X offers a handful of quality features, all so important to underwater photographers:

        -  Large 20.2 MP 1.0-inch CMOS sensor

        -  Bright F2.0 28-84mm lens

        -  Wide ISO range of 125-12800 for low light photography

        -  Full HD Videos (1080p/60p)

        -  Slim and Stylish - only 7.37 ounces (209g)

        -  Intuitive 3.0-inch touch panel

        -  Full manual control with Control ring and Mode Dial

  - The FG9X Housing introduces the highest and most professional standards of function, style and durability

  - Full access to camera controls and functions with clearly marked buttons

  - 67mm thread for macro and wide-angle wet lenses

  - Access to essential contact points on camera LCD screen with a new touch screen technology

  - Depth rated to 60 meters / 200 feet

  - Shock resistant construction

  - Ergonomic design

  - Double O-ring protection for a perfect watertight seal

  - Moisture Detector, Hand Strap and Port Cover Included

  - A complete accessory system available such as the following:

        -  Wide-angle and macro lenses

        -  Color correction filters, flashes

        -  Video lights

        -   All necessary adaptors and connectors

  - Manufacturer's warranty





FG9X Overview and Controls

The Fantasea FG9X housing is already proving popular among underwater photographers. Several Fantasea photographers and friends have been using the housing with great results - shooting both photo and video. I had a chance to get my hands on the housing for this review as well.

A big concern for using the G9 X underwater has been the need to rely on the rear LCD touch screen for full camera functionality. Fantasea has addressed this issue with 5 new buttons placed at essential points of the G9X's rear LCD screen. This ingenuitive idea will also help make the transition from using the camera on land to using it in the housing underwater even easier for topside shooters.

A view of the touch buttons accessible with the Fantasea housing.
Other controls are are accessed through traditional buttons and dials.

Fantasea housings are very easy to use underwater. The buttons have a large fingerprint that makes them easy to push, plus offer plenty of space for clear labeling. The knobs offer precise control of camera settings and respond the same as some very popular DSLR housings. Flared features on the right side thumb and fingers position make the housing very easy to hand hold, while the tripod mount allows you to attach a tray and build a larger system with strobes and/or video lights.

Inserting (and removing) the camera into the FG9X housing is easy, as it slides into place before being held steady by a spring-loaded pad on the housing's rear cover. This makes changing batteries and memory cards easy. The double o-rings are easy to access, inspect and clean.

A view inside the Fantasea Canon G9X housing.

The camera's front control ring, which is used to change exposure settings (aperture, shutter speed, ISO) is controlled with a knob on the front left side of the housing. The knob requires your left hand to turn, which should be readily available when shooting, whether using it to stabilize the housing itself or whether you have the housing mounted to dual arms/handles.

Fantasea has also included a moisture detector with a sensor on the (inside) bottom of the housing. The LED light is tucked away on the right side but is clearly visibile when the alarm goes off.

The top of the housing has a cold shoe mount, which allows you to add a ball mount for accessories, like focus light, GoPro and more. The cold shoe mount is an essential, but be sure to attach the accessory to the housing with a lanyard in case the ball mount slips out of the cold shoe.

Top view of the Fantasea Canon G9X housing.


Fantasea FG9X Advanced Features

The FG9X housing has two areas where advanced users can add accessories, making the housing versatile in handling many different shooting situations.

Flash Diffuser

The housing flash window cover is removeable and adaptable. When using the camera's on-board flash (macro without strobe/light), you can add the diffuser over the housing flash window to evenly disperse and soften the light.

Advanced shooters will opt for the fiber optic connection cover instead of the diffuser, which allows you to plug in one or two fiber optic cables for strobes.

67mm Port Threads

This universal port threading allows use of the best wide-angle and macro wet lenses for compact cameras. We've included several below, but you can visit Bluewater Photo to view all the Wide-Angle Wet Lenses and Macro Wet Lenses.



Fantasea FG9X Demo Video



Recommended Accessories

The following are just a few of the many accessories available to help you get the most from your Canon G9 X and Fantasea housing. Be sure to contact the experts at Bluewater Photo if you're interested in learning more.



Bluewater +7 Macro Wet Lens











Fantasea Bigeye M67 Wide-Angle Lens









Fantasea Radiant 1600 Video Light









Sea&Sea YS-03 Flex Arm Strobe Package













Fantasea Nano Double Ray Set









Fantasea Canon G9X Photos





Conclusion

The Fantasea FG9X housing is a very affordable way to house your Canon G9 X without sacrificing access to controls or quality. The housing is compatible with a wide range of macro and wide-angle wet lenses, plus the essential strobes, lights trays and arms. The buttons are clearly labled for easy operation underwater and the ability to use the touch screen is very cool.




Learn more and purchase the Fantasea FG9X Housing


ABOUT THE AUTHOR

Brent Durand is a weekend wanderer, story teller and image-maker from California.
BrentDurand.com   |  Facebook  |  Instagram

Brent is the editor of the Underwater Photography Guide and leads several photo trips and workshops for Bluewater Photo (see below).  Email Brent at brent@uwphotographyguide.com.

La Paz Big Animal Photo Trip (Oct '16)   |   Sri Lanka Wrecks & Reefs OR Whales & Dolphins Workshops (Feb '17)   |   Alor, Indonesia small group Photo Trip (Oct '17)

SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Acquapazza announces feature-rich underwater housing for the Sony A6300 mirrorless camera
By UWPG News

Acquapazza Sony A6300 Housing Overview

UWPG News
Acquapazza announces feature-rich underwater housing for the Sony A6300 mirrorless camera

Acquapazza has announced their housing for the Sony a6300 mirrorless interchangeable lens camera. Acquapazza housings have a great reputation for proven performance, along with a radical range of annodized aluminum colors.

One (unique) highlight of the Acquapazza housing is that the port opening is extra wide. This allows you to use Sony and Zeiss wide barrel lenses with ease. What does this mean? In competing housings we've seen to date, you must remove the port, then the lens, then open the back of the housing and remove the housing in order the change batteries (a frequent activity with Sony cameras). With the Acquapazza a6300 housing, you just open the back and remove the camera. Easy with much less time commitment and flood risk!

The Sony a6300 mirrorless camera is sure to be very popular with underwater photo and video shooters. Sony's impressive APS-C (crop) sensor is complemented by incredibly fast autofocus. Video shooters enjoy non-compressed file recording and up to 4K video resolution. Read our Sony a6300 Camera Review for Underwater.

Purchase:  Acquapazza Sony a6300 Housing

U.S. Retail Price:  $1,980

Availability:  Available for order now





PRESS RELEASE

ACQUAPAZZA announces the APSO-A6300

Key Features

  • An angled LCD viewing window.

  • The housing can accommodate the FE 90 mm F2.8 Macro G OSS easily.

  • It is also compatible with the ZEISS Touit 12mm f2.8, 50mm f2 and Vario-Tessar T E 16-70mm f/4 ZA OSS lenses. These are all high definition.

  • Manual focus gears are available for all lenses in the system chart.

  • It is possible to use both power zoom and manual focus with the Sony SELP1650 E Mount - APS-C 16-50mm F3.5-5.6 Zoom Lens.

  • The housing latch is made of aluminum.

  • Buttons are 8mm diameter.

APSO-A6300 is an APS-C mirrorless housing that ACQUAPAZZA has been developing for three years.



Angled LCD window

It features an angled window for viewing the camera’s LCD screen. This feature was popular on the ACQUAPAZZA housing for the Sony NEX5. Although this is normally a more expensive option, it was possible to do so without increasing the cost of the housing.

The angled window is very convenient when taking photographs using the LCD. This is especially true when the actiuon si quick and missing photographic opportunities is not an option. It is also a great option for capturing images of subjects that are close to the sea floor.





Wide Port Throat Offers Unique Lens Options

APSO-A6300 has been designed to accommodate the camera when it is equipped with an A mount lens. Thus, the diameter or throat of the port mount is large. This allows the use of “fat” bodied lenses like the Sony FE 90 mm F2.8 Macro G OSS, ZEISS Touit 12mm f2.8, ZEISS Touit 50mm f2 and ZEISS Vario-Tessar T E 16-70mm f/4 ZA OSS lenses. In addition, this makes mounting or changing the lens much easier.

This is a big advantage. Other company’s housings either do not offer these lens choices or mounting/changing lenses is more complicated.

For example, when removing a camera with a wide lens from the APSO-A6300 housing you simply open the rear door and remove it.

With other housings, it is necessary to remove the port, dismount the lens, open the rear door and then remove the camera. In essence, this adds three additional operations. Of course, this is additionally complicated as it is required even to exchange camera batteries or memory cards and especially so if you forget to do so and have to repeat the process!

Power zoom and manual focus with Sony 16-50mm lens

In many markets, the a6300 is sold with the Sony SELP1650 16-50mm power zoom as a kit. ACQUAPAZZA offer the option of being able to use both the power zoom and manual focus with this lens simultaneously.



Aluminum Housing Latch

Many housings have latches made of plastic. As this part is crucial to ensure that the housing closes properly and hence keep the camera kept dry, ACQUAPAZZA makes it from aluminum. This will ensure both ease of use and long life.

8mm diameter buttons.



Buttons on the APSO-A6300 have an 8mm Diameter

This makes them easier to use, even at depth or while wearing thick gloves.






Purchase the Acquapazza A6300 Housing


SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Sea & Sea proudly presents MDX-D500 Underwater Housing for the Nikon D500 camera.
By UWPG News

Sea & Sea MDX-D500 Underwater Housing Overview

UWPG News
Sea & Sea proudly presents MDX-D500 Underwater Housing for the Nikon D500 camera.

Sea&Sea has just announced their housing for the Nikon D500 DSLR camera. Sea&Sea has a long reputation for making great, innovative housings, and this camera / housing combo is sure to be very popular with Nikon underwater photo and video shooters.

The 20.7 MP Nikon D500 raises the bar in DX format Nikon cameras. The best feature is the revamped autofocus system, which boasts 153 AF points, 99 of which are cross-type. Improved focus tracking and a joystick for quickly adjusting the focal point location help capture fast action. This is a major jump for Nikon and puts the D500 into the consideration set of those who would have previously chosen Canon's dual-pixel AF technology.

In addition, the Nikon D500 has a large viewfinder with 100% coverage, 4K video resolution, and 10 fps continuous shooting with a buffer far larger than similar camera bodies (using XQD mem cards)... that's some processing power! If you haven't yet, you can read our Nikon D500 Pre-Review.

The Sea&Sea MDX-D500 housing brings ergonomic control of the D500 to underwater shooters. There are several new features, including a diopter adjustment dial and redesigned levers. The housing is also compatible with the Sea&Sea Optical YS Converter.  Below is the press release with full info.



Purchase:  Sea & Sea MDX-D500

U.S. Retail Price:  $3,599.95

Availability: On-going pre-order; Shipping in July 2016



Press Release

Most Anticipated Housing Since MDX-D300

SEA&SEA announces the MDX-D500 Underwater Housing for the Nikon D500 camera, the most anticipated housing since the MDX-D300. Newly designed features of the MDX-D500 housing greatly surpass its predecessor. New features include the compatible internal Optical YS Converter of the MDX-D500 versus the external TTL converter connector of the MDX-D300. The MDX-D500 housing also has redesigned levers and luminescent buttons that increase their visibility while shooting in low light conditions.

The Nikon D500 HD-DSLR camera is an upgrade to its predecessor the Nikon D300S with many improved features in a lighter camera body. The Nikon D500 has vastly improved sensor technology with a high-resolution 20.9 MP sensor, sports an Advanced Multi-CAM 20K AF system with 153 focus points, and can also focus in very low light conditions with its -4EV AF detection range, making it a great choice for underwater photographers.

       Converts the camera's TTL signal to a light signal. Both TTL and Manual Strobe control is compatible with Fiber-Optic Cable II (Not included).

Shutter lever, AF mode lever, AF-ON lever, and movie-record lever all have been re-designed with ergonomic shapes.

      Most levers and buttons will glow in dark environments.

      Conveniently switch lenses between dives without removing the housing back. Activate the Port Lock on the front of housing and push the Lens Release for quick and easy lens swap.

The camera's diopter adjustment dial can be operated from the housing.




Housing Features:

  • Equipped with two (2) Fiber-Optic Cable Sockets

  • Grip: Corrosion-Resistant Die-Cast Aluminum Alloy

  • Equipped with one (1) N-Type (2-pin) connector and one (1) HDMI accessory port

  • Depth Rating: 100m / 330ft

  • Equipped with two (2) Sacrificial Zinc Diodes (front/ rear)

  • Dimension (WxHxD): 324 x 210 x 141mm / 13.9 x 8.3 x 5.6inch

  • Compatible with Optional VF45 and VF180 View Finders

  • Weight: Approx. 3,200g / 112.9oz (housing only)

  • Built-In Leak Detector Sensor (Optional)

  • Compatible with SEA&SEA Strobes, Sea Arm 8, Fiber-Optic Cable II, Electronic sync Cords, Vacuum Pump System (TBA)

  • Body: Corrosion-Resistant Aluminum Alloy (machined)










Purchase the Sea & Sea MDX-D500 Underwater Housing




SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Aquatica announces housing for Nikon D500, with ergonomic control layout, advanced connectivity to strobes and more
By UWPG News

Aquatica Nikon AD500 Housing Overview

UWPG News
Aquatica announces housing for Nikon D500, with ergonomic control layout, advanced connectivity to strobes and more

Aquatica has just announced their housing for the Nikon D500 DSLR camera. This camera and housing combo will be very popular with Nikon underwater photo and video shooters who want a proven and reliable housing.

The 20.7 MP Nikon D500 raises the bar in DX format Nikon cameras. The best feature is the revamped autofocus system, which boasts 153 AF points, 99 of which are cross-type. Improved focus tracking and a joystick for quickly adjusting the focal point location help capture fast action. This is a major jump for Nikon and puts the D500 into the consideration set of those who would have previously chosen Canon's dual-pixel AF technology.

In addition, the Nikon D500 has a large viewfinder with 100% coverage, 4K video resolution, and 10 fps continuous shooting with a buffer far larger than similar camera bodies (using XQD mem cards)... that's some processing power! If you haven't yet, you can read our Nikon D500 Pre-Review.

The Aquatica AD500 housing brings pro-level control of the D500 to underwater shooters. Below is the press release with full info.

Purchase:  Aquatica AD500 Housing

U.S. Retail Price:  $3,195

Availability: mid-July at Bluewater Photo

Press Release



Introducing Aquatica AD500



Aquatica AD500 - Available on mid-July 2016

The new Aquatica AD500 housing is designed specifically for the long awaited Nikon D500 camera. With 21mp still image, 4K video possibilities, impressive level of low light performance, this Nikon D500 is a worthy addition to the DX format, a much appreciated sensor size for underwater photography.



The Nikon D500

The Nikon D500 camera finally joins the rank of the popular DX format Nikon DSLRs, to the underwater photographer. It brings interesting features.

The 20.7 MP Nikon D500 raises the bar in DX format Nikon cameras. The best feature is the revamped autofocus system, which boasts 153 AF points, 99 of which are cross-type. Improved focus tracking and a joystick for quickly adjusting the focal point location help capture fast action. This is a major jump for Nikon and puts the D500 into the consideration set of those who would have previously chosen Canon's dual-pixel AF technology.

In addition, the Nikon D500 has a large viewfinder with 100% coverage, 4K video resolution, and 10 fps continuous shooting with a buffer far larger than similar camera bodies (using XQD mem cards)... that's some processing power! If you haven't yet, you can read our Nikon D500 Pre-Review.



Nikon D500 Key Features:

  • UHD 4k from a 1.5x crop sensor

    • With flat picture profile for added post processing

    • On screen highlight warning

    • Power aperture control

  • Impressive AF performance

    • 153 point AF module

    • 55 selectable AF points

  • 100% viewfinder, with 1.0x magnification

    • The largest in cropped sensor DSLR

  • 10 frames per second rates

    • With 200 Raw files buffer using XQD

  • Rugged construction of Magnesium Alloy and Carbon fiber composite



The Aquatica AD500 Underwater Housing

Control Layout:

Aquatica designed the AD500 housing by carefully selecting the features that will improve performance for underwater imaging. We then ergonomically placed the vital controls where they were most needed, right at your fingers tips. At the core of this housing design one can trace over 30 years of expertise in this field. Years of knowledge that have pushed us forward in incorporating new ideas, concept and technological advances to these constantly evolving imaging tools.

ISO is one of the key controls in managing the exposure in video, hence particular attention was made in bringing this control at your thumb fingertip. Exposure compensation been crucial as well, a dedicated lever has been implemented for engaging it quickly when needed. The control pad can also be accessed quickly via a set of extended controls that brings it close to your right hand for easy access, same goes for the AF-ON lever with its wide range of options available through the CSM menu of the camera. The Fn1 lever located in front and Fn2 button on the rear also gives you access to a range of CSM features. Two oversized and conveniently placed buttons give a speedy access to the info and Live View activating features on the camera, recording is as easy as pressing on the dedicated lever placed strategically close to your thumb.

HANDLING THE HOUSING, THE BEST GRIPS IN THE INDUSTRY:

Handling is made with a pair of grips that have become the bench mark in comfort since their introduction over a quarter of a century ago. These grips are a perfect example of Aquatica’s philosophy, change should be implemented to improve a product, and not for the sake of novelty, when grips are as perfect as these are, leave them alone! Our grips are light, sturdy and form fitting. They contribute to making your underwater photography experience more pleasing and comfortable. Mounting points on top of them allows strobes arms, such as those from our Delta 3 line, to be mounted securely, freeing the top of the housing from unnecessary clutter.

VIEWING OPTIONS:

The Nikon D500 already is boasting the largest and best view finder on its category, viewing can further be improved underwater with a choice of two enhanced view finders. Two Aqua View finders are available to improve underwater viewing through the camera finder. The Aqua View 180o finder offers straight through line of sight viewing with a generous viewing area while the Aqua View 45o offer definitive comfort in viewing while shooting upward or for those down in the sand macro situations. Both accessory viewfinders are designed in such way as to minimize the blockage of the rear LCD when shooting using the rear LCD screen.

As a standard feature, the housing comes equipped with a quality multiple elements Galileo type eyepiece and the rear LCD has been angled to give the viewer a more comfortable viewing angle when using this one.

STROBE CONNECTION OPTIONS:

The Nikon D500 already is boasting the largest and best view finder on its category, viewing can further be improved underwater

  • 20080-UWT This AD500 housing  features our optional integrated TTL converter circuit board which is compatible with a wide range of underwater strobes. This converter is offering both automatic strobe exposure, either through optical relay using optical fiber or via standard and readily available electrical sync cords from your strobe manufacturers. Alternating between types of triggering is an easy affair, even in the field, with our easily replaceable bulkhead strobe connector design.

  • 20080-OPT Included with this optically set up housing version is the LED flash trigger. This LED trigger is powered by two popular “off the shelf” CR 2450 batteries and averaging 4,000 to 5,000 burst of light. This LED trigger slides into the hot shoe of the camera like any other hot shoe accessory would. The 20080-OPT version of this housing is ready to accept standard optical fiber sync cable commonly found on the market, there is no need for special proprietary or custom type cord, the optical fiber cord supplied by the strobes manufacturers are ready to use as is.

  • 20080-NK This version is set up with a pair of time proven Nikonos bulkheads connectors, the same available on all our current Aquatica DSLR housings. It is a well-established standard, which has been the back bone of strobe technology for decades and still by far the most distributed type of strobe connectors in the whole underwater photography industry, every strobe manufacturer offering then as a means of connection. This 20080-NK housing comes with not one, but two of these connectors installed. These, as well as the optical ones are easy to replace in the field, should one decide to alternate between way of triggering their strobes, no special tools are required and the operation is done in minutes.

  • 20080-KT This version is equipped with a trusted Ikelite strobe connector. Since many hard working underwater professional photographers prefer using Ikelite strobes and connectors for their ruggedness and reliability, Aquatica has made a point to have this housing version available to its users.

PORT SELECTION:

The Aquatica AD500 uses our excellent line up of existing ports for the DSLR line of housings. And simply put, a lot of effort has gone into giving you access to the most appealing lenses for this camera with the best port combination for them.

Since ports are such a vital part of the optical formula in any underwater photographic system, we at Aquatica, have built one of the most comprehensive selection available for underwater imaging. Our flexible modular system of extension rings, dome and flat ports is ready to face the challenge of constantly evolving lenses coming out on the market. The irreproachable optical quality of these ports have long made them the choice of demanding professionals from around the world.

Wide angle imaging requirement can be addressed with dome of 4”/100mm, 6”/150mm, 8”/200mm and 9.25”/230mm, from ultra wide angle close up situations to top quality over/under images. Our dome ports have you covered.

Macro imaging needs can be fulfilled using our recently introduced Mini Macro port, a vital part of the Aquatica ACU System, this port has a narrow frontal signature making lighting in tight corner easier. A bayonet mount is located on its front end for attaching our convenient ACU system flip holder with the potential of attaching up to two ACU wet diopter close-up lenses.

Tying the port system together are a set of fourteen locking extension rings, ranging in length from .65”/16.5mm to 3.82”/97.5mm. Port extensions are strategic partners in the optical chain, they serves two purposes, in the case of wide angle lenses, it helps optimize the performance of wide angle lens by properly placing their optical center with that of the dome port and for macro lenses, it give added length for accommodating longer focal length lenses such as the 105mm, or when using internal accessories such tele converter which may contribute to the added magnification of a given lens.

SAFETY FEATURES:

The Aquatica AD500 comes standard with our own Surveyor moisture and vacuum monitoring sensor circuit installed at the factory. The housing can also be ordered with the optional pressure extracting valve and pump installed at the factory. The visual and audio signal will attract your attention should any of the O-ring become damaged or hindered by sand, hair or any foreign objects that would compromise the sealing integrity of the housing. All that is required are a few simple steps for your peace of mind and knowing that your equipment is safely protected from the environment.

Securing of the housing is done with time proven stainless steel latches equipped with safety tabs. These are non-gimmicky, their solid track record has demonstrated that what they lack in fashion style, they more than make up in resistance to failure, jamming up or corroding over time. Chosen as a standard mean of securing highly valuables assets and equipment by scores of sensitive scientific and military equipment manufacturers, this method of securing is beyond reproach when it comes to reliability. Their simple and efficient design makes them reliable and they are a reflection of Aquatica’s commitment to rely on time and field proven technology.






Purchase the Aquatica for Nikon D500 Underwater Housing




SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Worth the Wait? You Betcha! Complete housing review, detailed feedback and underwater photos from Aquatica’s Sony a7 II housing
By Andy Sallmon

Aquatica Sony A7R II Housing Review

Andy Sallmon
Worth the Wait? You Betcha! Complete housing review, detailed feedback and underwater photos from Aquatica’s Sony a7 II housing

Aquatica waited. They were late to the party in releasing their housing for the much celebrated Sony A7RII. While other manufacturers raced each other to market with early A7 versions, Aquatica stayed cool, took a step back and looked more carefully at the A7 camera design. They watched the evolution of the A7 series become what it is today - a very noteworthy high performance camera. The payoff? They released a pro level housing for the Sony A7R II the first time out. No kits, no retrofits, no redesigns. They did it right the first time. Definitely worth the wait!



Designed for Serious Photographers

While other underwater housing manufacturers tried to design housings for the A7 series that focused on being small and compact, Aquatica took a different approach. Rather than try to make the housing really small, they opted instead for a slightly larger body that is still substantially smaller than most SLR housings. This has a two-fold benefit. First, it allowed the housing to accept all existing Aquatica ports and optical viewfinders, and second, the slightly larger platform offered much better stability underwater, yielding less camera shake when shooting finicky super high-resolution stills and video. So it’s true that bigger is better!





Purchase the Aquatica A7RII Housing

Additional resources:

Sony a7R II Review for Underwater   |   Sony a7R II Settings Guide   |   Sony a7R II Best Video Settings




































Photo left:  Aquatica A7RII Housing, Canon 8-15mm fisheye with Metabones adapter. ISO 400, f/11, 1/250
Photo right:  Aquatica A7RII Housing, Canon 8-15mm fisheye with Metabones adapter. ISO 200, f/11, 1/40



Housing Features

Grips – Aquatica’s great-fitting and comfortable grips are the same ones used on their SLR series housings for many years now. They are easy to hold with gloves on and have a smooth surface that will not rub against bare hands.

Camera Tray – A very well designed quick-release tray that indexes easily over two stainless steel rods and keeps the camera located rock-solid. The tray has a clever spring-loaded release tab that is easy to use and positively click locks. No accidental release of the camera and fewer alignment issues with controls.

External Port Release Lever – Sits low on the right and is tucked out of the way to prevent accidental damage caused by rough handling, or getting rolled in surf.

External Lens Release Button – A stainless steel button located on the lower left side recessed below the port mount so it does not interfere with port mounting.

Sacrificial Zinc Anodes – Two zinc anodes located on the bottom of the housing, one for the front and one for the rear half.

Vacuum and Moisture Sensor System - The housing comes standard with Aquatica’s built-in vacuum and moisture sensor circuit. A small window on the housing back with an LED light indicates good vacuum with a green light, or leak with a red light.  A vacuum pump and external valve hardware version is also factory available at a modest cost and is recommended. My test housing was fitted this way.



Controls

The Aquatica A7RII housing has every control necessary to create world-class images. Most are located so that hands do not have to leave the grips, and with a few dives for familiarization my eye did not need to leave the viewfinder. Here’s my short list of the most important controls.



Housing Left Side

 Zoom/Focus - A large, easily reached knob by the left index finger and middle finger together allows zoom/focus control while still maintaining hold of the left grip.  The control has the added benefit of being spring loaded so it will disengage with the internal gears for easier camera mounting.

Review Lever – “Chimping” is made quick and easy by a small lever mounted high on the left that is thumb activated without removing your hand from the left grip.



Housing Right Side

Shutter Release Lever – The shutter release lever has a large (and easy to reach with the index finger) surface and a very nice progressive pull to it. It is easy to find while looking through the viewfinder so there won’t be any “hair trigger” shots.

Front Dial Control Knob - This controls aperture (can be set for shutter speed control too) and is reachable from the right grip by holding the grip low and rotating it with middle and ring fingers.

Rear Dial Control Knob - This controls shutter speed (can be set for aperture control too) and was easy to reach with the right thumb while maintaining a grip on the handle.

Video Record Lever – This is located under the Rear Dial Control and tucked away so it doesn’t interfere with still shooting. It was reachable by thumb while maintaining a slight low grip on the right side.





Housing Top

On/Off Lever – A large easy to access on/off lever sits on the top right.

Mode Dial Access Knob – On the top right near the viewfinder.

Exposure Compensation Control Knob – On the top right next to the Mode Dial Knob

C1 lever – A special lever controls the C1 function control. It is primarily used to toggle between the Electronic Viewfinder (EVF) and the rear LCD. This was a very welcome control as it made reviewing images and changing back to the EVF quick and easy. Housings without this feature are difficult and slow to use. The C1 lever is easily right thumb accessible without releasing the right grip.



Housing Back

 Set Lever – A large very conspicuous lever with the word set on it is easily reached by the right thumb while still maintaining hold on the right grip. It activates the center rotary dial set button. This is a must-have control for anything requiring fast changes in menu.

Control Wheel (Rotary Dial) Access Knob – A large knob on the lower right allows access and scroll control. It is reachable by right thumb but requires the right grip to be partially released.

ISO Button – Is at the right (3 o’clock position) stainless steel button (of 4 buttons) that when depressed, allows access to ISO. It is reachable from the right by thumb. Note that the Control Wheel (Rotary Dial) Knob listed above must be rotated after the button is pushed. The ISO button is directly above the Control Wheel Knob, so it is easy to access and then change ISO with this housing.

There are other controls including two more assignable C buttons. A lever for C2 on the right side and a button for C3 on the back, an AE-L AF/MF lever and set button, menu and delete button, and an Fn button all on the back.





Diving the Aquatica A7RII Housing

Like Aquatica, I waited too. I am not one to adapt early, I am “old school” (originally a film guy), but had heard great things about the Sony A7R II camera, so was excited to try one out. Being a “Canon guy” too, I was especially excited at the prospect that I would be able to use my Canon lenses (with an adapter).  I had been looking at A7RII housings, but none currently had all the controls that I required, nor offered them in an easy to reach design. When Aquatica announced the A7RII all that suddenly changed though. So, I took a new Aquatica A7RII housing and Sony A7RII camera with a Metabones MkIV adapter, along with my trusty Canon 8-15L f4 zoom and 100L f2.8 IS lenses on a trip to Raja Ampat, Indonesia to give it a try.  Here’s what I found out.



































Photo left:  Aquatica A7RII Housing, Canon 8-15mm fisheye w/ Metabones adapter. ISO 400, f/22, 1/250
Photo right:  Aquatica A7RII Housing, Canon 8-15mm fisheye w/ Metabones adapter. ISO 400, f/18, 1/250



Viewfinders

Not having an optical viewfinder was a big change for me at first, but once used to the electronic viewfinder I found that the display, though smaller than my DSLR, was more like looking at the image on a computer screen. I still prefer the optical VF on my Canon 5D Mark III, but the EVF on the Sony had some good points that my Canon did not. It gave me a more accurate display of what the final image would look like and also adjusted the available light levels. The Aquatica A7RII housing is compatible with Aquatica’s very easy to use 180 viewfinder and the magnified view that it provides really helped me to make the transition from optical to electronic finder much easier. For SLR shooters thinking about switching to an A7RII system, I would highly recommend the 180 VF. For compact and mirrorless shooters upgrading to the A7RII, it is still a very useful accessory and I would also recommend it, if the budget allows.

Weight and Balance

The port system for Aquatica housings is vast. I chose the Aquatica 6” acrylic dome for the Canon 8-15mm for its compactness, ease of travel and movement underwater because I knew that I’d encounter some high current dives in Raja Ampat. For the Canon 100mm macro, Aquatica’s new conical shaped mini macro port (with an extension ring) did the job well.  Aquatica also provided their new ACU close up lens kit with a double flip holder and both a +5 and +10 wet diopter.  With a 100mm macro lens and all this glass up front I was a little worried that the system would nose dive, but to my surprise it remained fairly well balanced underwater in the macro configuration and did not pitch down. The 6” dome (being acrylic) did not add appreciable weight, even with the extension and my heavy 8-15 zoom, so was also well balanced. I added about 40 ounces of positive buoyancy to my strobe arms that helped offset the weight and the little housing was by my estimate just about 1 lb. negative in wide configuration and a little more in macro - maybe about 1.5 lbs. Nicely balanced, yet still able to set it down on the bottom if necessary, without blowing away in the current.



Housing In Use

Raja Ampat delivered and I was able to put the system through its paces. I was challenged with strong nutrient rich currents and quickly changing torrential down pours to partly cloudy to full sunny skies all in the length of one dive. With underwater visibility ranging from 20’ to 100’, the environment ran the little Aquatica A7RII housing through the gauntlet for 10 days straight. I shot lots of reef scenics, schooling fish, wobbegongs, manta rays and got into some great macro at night. The housing really shined when I needed to access controls fast. It is well designed and rugged. All the controls necessary to make images in rapidly changing situations, like current, clouds to sun and vice-a-versa, and fast approaching animals worked consistently, were smooth and efficient. The design team and engineers at Aquatica are to be applauded and should take a bow as their well thought out housing shows off their understanding of just what it takes to produce a high quality product that works and that has the quick reflexes a pro requires when on assignment. I am a fan!

I enjoyed my time shooting with the Aquatica A7RII housing and look forward to more time in the water with the system. A couple of things worthy of note for anyone intending to use Canon macro lenses with this camera: don’t! It requires an adapter and from my online research it appeared that the Metabones Mark IV adapter for Canon EF (full frame) to Sony E-Mount would be exactly what I needed, and it was. On the Metabones website it lists the Canon 100mm f2.8L macro IS as compatible, and it worked fine in the office pre-trip. Once underwater, however, it would focus, but not lock on and hold, hunting badly instead. It was so frustrating that I finally gave up using it altogether. Metabones does note that longer telephoto lenses will likely hunt more than others and I did not experience any hunting with my 8-15mm. So for a Canon lens user I have to recommend that for macro at least, to stay with the Sony 90mm macro G OSS lens. I haven’t been able to try one yet, but have heard from those using it that it focuses just fine. One other point to make for Canon lens users if you plan to do video capture with this camera. On the Metabones website it also notes that in video capture mode the phase detection autofocus will not work and it will be contrast based AF only. To me, that would kind of defeat the purpose of this camera with Canon lenses for video shooters. So for video the Sony 16-35 or their 28mm with wide adapter are better choices. Stills were fine with the Canon 8-15 and many other lenses are also listed as compatible.





Conclusion

The Aquatica A7RII housing is one of the finest currently available for the Sony A7RII camera. It offers the shooter professional level control, is well balanced and very rugged. My test housing had no visible scratches after being flogged for 10 days in high current and bouncing around the bottom of small inflatables. Aquatica’s powder coated exterior is tough as nails and probably the reason that many tech, wreck, cave divers and the U.S. Navy have designated Aquatica as their number one choice for the everyday tough environments they use them in.  That and it is manufactured in nearby in Canada using all USA-made aluminum marine alloy. The housing’s vacuum system was simple and worked well everyday. I left it on purposely overnight to see if it would “eat” batteries. It remained on all day for 10 days of diving and the battery never blinked.

Overall the Aquatica A7RII housing’s build quality, reflexive easy to use control set, underwater balance and rugged exterior make this a “two-thumbs up” housing for the Sony A7RII. It is priced very competitively too.





Purchase the Aquatica A7RII Housing

Additional resources:

Sony a7R II Review for Underwater   |   Sony a7R II Settings Guide   |   Sony a7R II Best Video Settings




ABOUT THE AUTHOR

Andy Sallmon is a freelance underwater photographer specializing in marine wildlife, scuba diving and ocean natural history. His images have been published in numerous magazines and books, some even gracing the walls of notables such as the Smithsonian Institute and the Monterey Bay Aquarium.

When not on assignment Andy stays busy as a manufacturers representative for several leading brands of underwater photographic equipment including Aquatica Digital, Beneath the Surface, Light & Motion and Sea and Sea.

His website is: www.seait.com

SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Nauticam releases housing for the Nikon D500 with new TTL trigger and important ergonomic updates
By Brent Durand

Nauticam Nikon D500 Housing Available

Brent Durand
Nauticam releases housing for the Nikon D500 with new TTL trigger and important ergonomic updates

Nauticam has just released their housing for the much anticipated Nikon D500 DSLR camera. This is the first housing announcement we've seen for the camera, which is expected to be very popular with the Nikon camp of underwater photo and video shooters.

The 20.7 MP Nikon D500 raises the bar in DX format Nikon cameras. The best feature is the revamped autofocus system, which boasts 153 AF points, 99 of which are cross-type. Improved focus tracking and a joystick for quickly adjusting the focal point location help capture fast action. This is a major jump for Nikon and puts the D500 into the consideration set of those who would have previously chosen Canon's dual-pixel AF technology.

In addition, the Nikon D500 has a large viewfinder with 100% coverage, 4K video resolution, and 10 fps continuous shooting with a buffer far larger than similar camera bodies (using XQD mem cards)... that's some processing power! If you haven't yet, you can read our Nikon D500 Pre-Review.

The Nauticam NA-D500 housing will bring the full power of the D500 to divers' fingertips. Below is the press release with full info.

Purchase:  Nauticam Nikon D500 Housing

U.S. Retail Price:  $3,500

Availability:  Now

PRESS RELEASE



Introducing NA-D500



A New Era of DX Format Performance

Nauticam NA-D500, Model Number 17220
Shipping May 23, 2015



Nauticam is pleased to unveil NA-D500, the latest release in the world's finest line of underwater camera housings.  Nauticam is the market leader in ergonomics, build quality, and reliability.  Built on a foundation of innovative product design and modern manufacturing technology, NA-D500 is the ultimate accessory for the exciting new Nikon D500 camera. And it's available now...



The Nikon D500

The new Nikon D500 may be a reboot of the popular segment last featuring D300s six years ago.  It could be the D400 that never came, or it might be an entirely new product segment. Regardless of classification, there has never been a Nikon DX camera with this level of autofocus and continuous shooting performance before, and D500 provides a compelling alternative to pro bodies for fast action capture in remote environments.

The D500 features autofocus speed, continuous shooting speed, and a deep buffer unlike any DX body to come before it. It uses the same Multi-CAM 20K  focus system as the professional D5, with 153 focus points (99 cross-type sensors). D500 has more cross-type focus points than the previous pro body D4s had total focus points, and they are spread wider across the frame.  In fact, they are spread right to the edges. The difference between D500 and previous APS-C systems is even more striking; both the Nikon D300s and D7200 feature a total of 51 focus points (15 cross-type). The D500 a shooting experience can really only be compared to pro cameras, but in a compact body size and attractive price point.  Pro performance for the masses!

The D500 also introduces a new, 180k pixel RGB metering sensor.  This metering sensor drives the advanced Nikon exposure system, and is also used to provide scene data for 3D focus tracking, improving accuracy.  The autofocus system in the D4s was already one of the best available, and the improvements offered by D500 will elevate performance even further in a body at 1/3 the price!

The 10 fps continuous shooting speed (with AF) and a 200 shot RAW buffer (using XQD cards) keeps up with the fastest action.  This is an incredible increase in continuous shooting capability.  The D7200 camera can only buffer 17 14-bit Raw frames, and the Canon 7D Mark II can only buffer 31.

The D500 viewfinder is the largest Nikon has ever featured on an APS-C camera, with 1.0x magnification and 100% coverage.  The EN-EL15 battery is capable of 1,240 shots per charge (according to the CIPA rating). The camera can record 4k video at 30 frames per second, and is weather sealed for use in extreme environments.

The Nikon D500 is an extremely important camera for underwater photographers, and one of the most exciting Nikon product releases in years.  The APS-C format has distinct advantages in available underwater optics and travel size, and the D500 will no doubt produce amazing image sequences in fast action, fast moving situations.



Nikon D500 Key Features:



  • 20.7 MP APS-C (DX Format) sensor

  • 153 point AF module with 99 cross-type points

  • 180,000 pixel RGB sensor for metering and subject recognition

  • AF point joystick

  • 10 fps shooting for up to 200 shots (lossless compressed 14-bit Raw to XQD card)

  • 4K (UHD) video from 1.5x crop of sensor

  • 100% coverage viewfinder with 1.0x magnification

  • 2.36m dot tilt up/down touchscreen

  • Wi-Fi and Bluetooth connectivity with NFC for setup

  • Mic and headphone sockets

  • USB 3.0 connector



The Nauticam NA-D500 Underwater Housing

Nauticam housings are evolutionary marvels, with advancements from previous sixteen Nauticam for Nikon systems providing the foundation that this new model was built from.  Customer feedback is integrated at every possible opportunity. The cumulative experience of the Nauticam user base provides constant inspiration for innovation, and is a key strength of the brand.

The new Nauticam NA-D500 housing further enhances the market leading Nauticam ergonomic experience with improved control placement, a new more sophisticated flash triggering system (with optional TTL upgrade), and reduced size / weight thanks to cutting edge manufacturing processes.

External Flash Triggering

The entire external flash triggering system has has been reworked from the ground up in NA-D500, increasing ease of use, setup convenience, and reliability.  A new LED flash triggering system is standard in every housing!

This optical flash trigger can fire at the full 10 fps of the camera, making it the ideal solution for the rapid fire fast action shooting that the D500 is so well suited for. Optical systems, with fiber optic cables linking the external flashes to the housing, are far more reliable than any electrical sync cable system.  There are no connections to flood, or fragile wires to break, and nearly every popular underwater strobe supports optical triggering.

The LED trigger circuitboard is mounted directly to the front of the housing, and connected to the camera with a hotshoe cable.  This new system is more powerful than the hotshoe mounted LED triggers used in the past, and is compatible with all currently available optically triggered flashes!  Powered by two CR2032 batteries, battery life is measured in the tens of thousands of flashes, driven by incredibly efficient electronics.  With good batteries, we expect 3-5 years of service, up to 50,000 exposures.

Users of legacy flashes without optical triggering are able to add accessory Nikonos (26074) or Ikelite (26075) style bulkheads for electrical flash sync.  These bulkheads plug into the LED trigger board for clean cable routing, and reliable connection.



The redesigned LED Flash Triggering System has allowed for a much lower housing height.  This the smallest, easiest to pack Nauticam DSLR housing for Nikon yet!



Accessory TTL Converter



NA-D500 will also be compatible with the new Nauticam TTL Converter!  This user installable upgrade provides accurate automatic TTL flash exposure with a number of popular flashes, and offers both optical and electrical strobe triggering in a single unit!


Optical triggering, using an led integrated into the board and fiber optic cable, works well with modern flashes like Inon Z-240, Sea & Sea YS-D2, and more.  Electrical triggering supports Ikelite DS- and Sea & Sea YS-250 strobes connected via an electrical sync cord.

Accurate automatic TTL flash exposure has been a favorite feature of Nauticam photographers using cameras with pop up flashes, and we are excited to bring this advanced flash control functionality to the NA-D500 housing!

  • TTL Converter for NA-D5 and D500, Sea & Sea YS-D and Inon Series Strobes (26307)
  • TTL Converter for Ikelite DS- Strobes, Sea & Sea YS-250 Available Soon



Unmatched Ergonomics

The right grip is mission control for the D500 camera, accessing many of the frequently used camera functions.  Oversized levers are identifiable by feel, allowing tactile operation while framing with the optical viewfinder.  The most frequently accessed fingertip controls (Shutter Release, Main Command Dial, and Sub Command Dial, Video Record, and AF-ON) are located here. ISO, the primary exposure control used by DSLR video shooters,  is accessed by a convenient thumb lever under the right grip.  INFO, useful for calling up the camera settings on the 3.2" rear color LCD, is placed at the right thumb.

A "pinky lever", placed just under the front sub-command dial, accesses the Fn1 button.  This can be linked to a number of assignable functions.

The new AF-Mode Lever is a significant improvement, and one based on feedback from Nauticam customers in the field.  Nikon AF Area modes have become so powerful that shooters are regularly switching between 3D Tracking, Auto Area AF, and Single Area modes.  The AF-Mode lever is now easily located by feel from the left handle!  A separate AF-M lever is positioned above this lever, and identifiable by feel.

A double thumb lever accesses playback and the assignable Fn2 Button.



Extensive Customization for a Tailored Ergonomic Experience



The Nikon D500 camera in a Nauticam NA-D500 housing offers three assignable pushbuttons (AF-ON, Fn1, and Fn2) that can all be accessed from the housing handles.

These custom functions can be overwhelming at first, but the creative options they unlock can be incredibly valuable in the field.  In short, these assignable buttons mean less time digging through camera menus to change camera functions, and more time capturing the scene as it unfolds.  There isn't a right way configure these systems.  Every photographer and shooting scenario has unique demands.  Some ideas are listed below:

  • 1 Step Spd / Aperture, allows changing exposure settings in full f-stop increments.  Think about changing from a wide angle scenic mode with relatively open aperture and slow shutter speed to a close focus wide angle shot that requires a closed aperture to shrink a sun-ball.

  • My Menu, a customized panel with frequently accessed menus settings

  • Access Top Item in MY MENU, actually jumps into a frequently accessed sub menu structure for the top level My Menu selection, saving at least two button presses.  (ie min shutter speed in auto iso mode, or quickly define a preset white balance)

  • Quickly access another metering mode, toggling between the selected metering pattern and an alternate that more appropriately evaluates the current scene.

  • Flash disable / enable, this is a big one!  Toggles external flashes on and off, allowing a switch between artificial light shooting (continuous shooting speed limited by flash recycle, and shutter speed limited by the strobe max sync speed at 1/250) to silhouette mode using only ambient light (full 12 fps continuous shooting speed, unrestricted flash sync speed).

  • AF-area mode + AF-ON – very cool functionality, for a quick way of accessing a focus mode other than the mode currently assigned and activating it while held down.  Placed at the right thumb via the re-positioned PV lever, the current focus mode be overridden with something like auto area focus for quick grab shots where there isn't time to move the selected autofocus point, or change focus area patterns.



Nikon DX Underwater Advantages

 Smaller rig, lenses, smaller domes, and more money for dive trips. Full frame systems have been all the rage in recent years, but it is hard to ignore the benefits of the APS-C sized sensor in Nikon DX bodies for underwater photography.  DX lenses tend to be less expensive than their full frame counterparts, as do the smaller domes that they work well with.  This savings adds up, and the available lens selection is an extremely versatile one.

  • A fisheye that zooms!  The Tokina 10-17 is the ultimate super wide field of view range, and full frame systems don't have it.  The 10mm end, with 180 degree diagonal field of view, is the perfect angle for close focus wide angle subjects or big animals that are approachable.  The 17mm end covers more skittish subjects that won't come close, or more portraits styles shots of medium and large subjects.

  • Super Wide Zooms.  The full frame rigs require really big dome ports and expensive lenses, to cover this 110° range without fisheye distortion.  DX cameras, paired with the Nikon AF-S DX 10-24mm f/3.5-4.5G ED Zoom provide amazingly good overall sharpness and corner performance even in smaller 180mm dome ports.  This is a tremendous benefit for travel, as the smaller dome is much easier to pack, and significantly lower in weight.

  • Extra Macro Reach.  Take the most macro magnification possible with a full frame system and a Nikon 60 or 105mm lens, then crop the center 2/3 of the frame.  That is the image framing that a DX camera grabs in camera!   Adding a Nauticam Super Macro Converter to the 105, or Compact Macro Converter to the AF-S 60 allows for incredible magnification.

  • Handy Mid-range Zooms.  Several mid-range zoom lenses, most notably the Sigma 17-70 series, provide coverage for a wide variety of almost wide angle to closeup shooting scenarios. These lenses handle a range very similar to that covered by the built in zooms in the compact cameras that many underwater photographers cut their teeth on.



Key Features



Patented Port Locking System


Unveiled on the very first Nauticam DSLR housing in 2009, this locking lever has become a signature of the Nauticam brand.  No twisting or threading action is required to mount a port,and it locks securely in place with this lever.  Nauticam also offers locking extension rings, meaning a dome will never twist, even when used with a long extension ring.





Housing Locking Latches


The industry's easiest to use housing closure system, requiring very little hand strength to close, secures the housing back in place. The latches are safely locked, but easy to open for a quick battery or memory card change.







Multi Controller Pad


Located within easy reach of the right thumb, virtually recreates the Nikon D500 multi selector allowing full multidirectional use of this powerful too. No other manufacturer has it, and with 55 user selectable focus points to choose from, photographers need it.







Integrated Vacuum Monitoring and Leak Detection


Circuitry included as standard equipment provides constant monitoring of water tight integrity when combined with an optional Nauticam M16 Vacuum Valve II (PN 25625).







Vacuum Reset Button in Port Mount


A simple vacuum reset pushbutton placed in the port mount allows the vacuum system to be calibrated and initialized from the housing front.  Ideal for quick lens swaps!







Stainless Steel Handle Brackets

Stiffening handle brackets are included with the housing.  These brackets eliminate any flex or wobble when using big strobes, and provide multiple attachment points for lanyards, a hand strap, and other accessories.





Ergonomic Rubberized Grips

Another legendary Nauticam feature, these rubberized grips have been used every Nauticam DSLR housing release, and are some of the most comfortable in the business.







Clear Control Labeling



All camera controls are clearly labeled, allowing easy identification.





Integrated Vacuum Check and Leak Detection System

The Nauticam vacuum check and leak detection system is shipped with NA-D500 as standard equipment.  Combined with an accessory vacuum valve (PN 25625), this monitoring system provides constant updates on the water tight and safe-to-dive status of the housing.  A simple color coded LED lighting system lets the user know that the vacuum is solid, or that the housing is losing vacuum. Leak detection is built into the same circuit, so if there is water intrusion, an audible and visual indication will occur.

The Nauticam system is temperature compensated, eliminating false alarms caused by a change in outside temperature, or from a camera heating up on an action packed dive.





Ease of Use

No system is easier to assemble or break down.  The camera drops into the housing with a quick release camera tray.  The camera tray has an extending bracket that allows the AF-M selector to be easily positioned to match the camera.  No controls need to be preset, as housing functions for dials and switches align automatically (on/off, af-m, still photo/video).   The large 120mm housing port opening allows even the largest popular pro Nikon wide angle lens (14-24 /2.8G) to be used, and the camera can even be mounted in the housing with this large lens attached.



Viewfinders

The standard optical glass viewfinder is very good and travel friendly, but many photographers prefer the ease of a magnified viewfinder with adjustable diopter. Nauticam produces a “straight” 180º enlarging viewfinder and a 45º angled enlarging viewfinder to enhance the ease of close quarters work often associated with macro shooting. Both viewfinders have high quality optics, and allow bright viewing of the entire image. A patented external dioptric adjustment allows personal adjustment to a sharp-as-a-tack standard underwater and viewfinder changes can be executed in less than 30 seconds without using tools. Exceptional composition and focus accuracy have never been more accessible.



Premium Professional Optics

Experienced shooters know a camera is only as good as the lens in front of it, and the same is true when choosing optics for an underwater camera system.  Four optically coated glass dome ports (250mm, 230mm, 180mm, and 140mm diameters) and a series of acrylic ports support popular lenses from Nikon, Sigma, and Tokina. Port configurations are extensively tested at Nauticam to determine the ideal extension ring length for best performance.

For macro and super macro shooting, the Nauticam Super Macro Converter is a revolutionary accessory. This is an entirely in house design, optimized for use in water.  The water contact correction offers the highest overall sharpness, free from chromatic aberration and purple fringing, with reproduction ratios exceeding 2:1 when used with a Nikon AF-S 105mm /2.8 VR Lens.

Build Quality

Nauticam build quality is simply unmatched, using cutting edge product design and modern, innovative manufacturing techniques that result in service-free reliability. A bit like a fine Swiss time piece, the complexity under the hood results in a trouble free user experience that just works, and keeps working for years to come.



Recommended Accessories

Magnifying Viewfinders

  • 180º Enhancing Viewfinder (32201)
  • 45º Enhancing Viewfinder (32203)

Optical and Electrical TTL Converter

  • TTL Converter for NA-D5 and D500, Sea & Sea YS-D and Inon Series Strobes (26307)
  • M14 Nikonos 5-pin Bulkhead II with Red Micro-Match Connector (26074)
  • M14 Ikelite Style Bulkhead II with Red Micro-Match Connector (26075)

Other Accessories

  • Patent Pending Super Macro Converter (81201), providing 2.3:1 reproduction ration with the popular AF-S 105mm /2.8G VR Macro Lens
  • M16 Vacuum Valve (25625)
  • Complete line of flat and dome ports for all major lenses, available in acrylic and glass
  • Locking port extension rings from 10mm to 90mm
  • Monitor/Recorder Housing for Atomos Ninja2 (17902) or Shogun (17904)
  • Monitor Housing for SmallHD 502 Monitor (17906)
  • Fiber optic cables for Inon (26211) and Sea&Sea (26212)
  • Full line of mounting accessories for lighting, including mount balls, strobe adapters, arms, clamps, and specialty items
  • Multiple styles of lanyards
  • Lens holders, including flip-up
  • Focus and Zoom gears for many Nikon, Tokina, and Sigma lenses
  • Port Adapters for Aquatica, Hugyfot, Ikelite, Inon, Nexus M5 & M6, Sea & Sea NX, Seacam, Subal Version 3 & 4, and Zillion
  • Handle accessories including smaller handles, handle extensions for cold water diving
  • Spare Housing O-Ring (90134)




Details and Specifications

  • Depth Rating:  100m
  • Weight: 3.02 kg
  • Dimensions: 354mm x 188mm x 134mm (W x H x D)

Model Number: 17220
USA Retail Price: $3500
Availble Now at Bluewater Photo






Purchase the Nauticam Nikon D500 Housing




SUPPORT THE UNDERWATER PHOTOGRAPHY GUIDE:

The Best Service & Prices on u/w Photo Gear



Visit Bluewater Photo & Video for all your underwater photography and video gear. Click, or call the team at (310) 633-5052 for expert advice!




The Best Pricing, Service & Expert Advice to Book your Dive Trips



Bluewater Travel is your full-service scuba travel agency. Let our expert advisers plan and book your next dive vacation. Run by divers, for divers.




Syndicate content
